Flat Wire Stainless Steel Architectural Spiral Weave Conveyor Belt Mesh For Building
Architectural Spiral Weave Mesh Product Description
Flat Wire Stainless Steel Architectural Spiral Weave Conveyor Belt Mesh is a specialized metal mesh product that combines industrial conveying functionality with architectural aesthetics. It is widely used not only in conveyor systems for food processing, baking, and industrial production lines, but also increasingly in architectural applications such as façade cladding, sunshades, ceiling systems, and interior partitions.
This type of mesh is manufactured from high-quality stainless steel materials, commonly grades 304, 316, or 316L. These materials provide excellent resistance to corrosion, high temperatures, and mechanical wear, making the mesh suitable for both indoor and outdoor environments, as well as harsh industrial conditions. The “flat wire” design refers to the use of flattened stainless steel strips instead of round wires, which increases the contact surface area and enhances stability.
The spiral weave conveyor belt mesh is composed of three main components: flat spiral wires, connecting rods (cross rods), and sometimes reinforcing edges or chains. The flat spiral wires are formed into continuous helical shapes, which are then interlinked to create a uniform mesh surface. Cross rods are inserted through the spirals to hold them in place and maintain the structural integrity of the belt.
The spirals are assembled by interweaving adjacent spiral wires. During this stage, straight cross rods are inserted through the center of the spirals at regular intervals. These rods act as connectors, locking the spirals together and forming a continuous belt structure. The ends of the rods may be welded, bent, or fitted with edge reinforcements to prevent displacement.
Architectural Spiral Weave Mesh Product Specifications
| Name |
Decorative Woven Metal Wire Mesh |
| Use |
Architectural / Interior Design / Shopfittings / Partitions |
| Material |
Stainless Steel wire, iron wire, copper, aluminum |
| Rod diameter |
0.9mm,1.2mm,1.5mm,etc. |
| Color |
gold,silver |
| Dimension |
Customized |
| Place of Origin |
Hebei China |
| Sample |
Provided |
Architectural Spiral Weave Mesh Key Features
Key features of this product include high strength, excellent load-bearing capacity, smooth surface, and good air and heat permeability. The open structure allows efficient airflow, drainage, and heat transfer, which is essential in processes such as baking, drying, and cooling. In architectural use, the mesh provides a modern industrial look while allowing light and visibility control.
Architectural Spiral Weave Mesh Applications
Architecture&Decorative metal mesh is widely used in interior and exterior decoration of the advanced building. Such as museums,government buildings, grand ballrooms, hotels, residential areas, jewelry stores, elevators, wall cladding and etc.
About Our Company
Founded in 2000, Anping Velp Wire Mesh Products Co., Ltd has grown from a 10-person team to a 5000 sqm facility with complete departments including Production, Sales, After-sales, Technology, Research and Development, Procurement, and Design. We have established a strong reputation as a premier manufacturer of expanded metal, perforated metal mesh, safety walkway grating, stainless steel weave mesh, and building stucco mesh products in China.
Frequently Asked Questions
Q: Can I get a free sample?
A: Yes, we provide free samples anytime.
Q: Is there quality control on all production lines?
A: Yes, all production lines have adequate quality control.
Q: What are your payment terms?
A: T/T 30% as deposit, and 70% balance before delivery. We'll show you videos of products and packages before final payment.
Q: What is the delivery time?
A: Generally 15 days after receiving advance payment. Specific time depends on items and order quantity.
